POLYZOL CTS PLUS (CTS229)

CTS229 is an SBQ emulsion suitable for textile printing and for graphic printing on low mesh counts while still requiring sharp definition and good detail retention. It can be used with water-based and plastisol inks.
This emulsion is suitable for CTS (Computer-to-Screen) systems.

  • One pot Photopolymer emulsion, Ready to use

  • Excellent latitude and high definition

  • Fast exposureLong print durability

  • For computer to screen printing

Properties

Type : One pot / Purple colour
Solid content (unsensitized) % : 39 %
Recommended inks : Water based ink, Textile ink and Plastisol ink.

Main Characteristics

Special safelight is not essential, but yellow or weak illumination is desirable.

Caution

Preparing the Screen

Manual

Set the screen on edge slightly inclined away from the operator and then follow this procedure:

  • Apply one or two coats of this emulsion, wet on wet, to the print side of screen.

  • Apply one or two coats of this emulsion, wet on wet, to the squeegee side of screen.

  • If a higher build of emulsion is required extra coats should be applied, wet on wet to the print side.

    Automatic

  • When using an automatic coating machine, a simultaneous single coat on each side of the screen is recommended.

  • If higher builds are required, extra coats should be applied to the print side of the screen.

Coating

Put coated screen in hot air oven with squeegee side up. Do not exceed 40 ํC.

Drying

Exposure

Table of Exposure GuideComputer to screen process (For Polyester screen mesh 77/cm. White)

* The above is for guideline purposes only. Please use a grayscale exposure calculator to identify optimal exposure time.

Place the screen in washout booth and gently spray both sides, increase the spray pressure slightly. Continue developing until or parts of the image appear clean and sharp.

Developing

Check for pinholes or blemishes. Spot out with a suitable filler with emulsion dried and re-exposed.

Spotting

  • Use Screenstrip Powder (SST002), Screenstrip Liquid (SST004) or Screenstrip Paste (SST007).

  • Apply the solution to both sides of the screen with a soft brush. Rub into the entire stencil area.

  • Leave the screen for 2-3 minutes, but do not allow the product to dry.

  • Wash with mains pressure water. Use a high-pressure water gun if required.

Reclaiming the Screen

Emulsion :
5 Kg and 1 Kg

Standard Packing

  • Storage temperature should not be over 25 ํC. It should be stored in a dry location with good
    ventilation and away from heat or ignition sources.

  • When stored under these conditions, It is expected to have a shelf-life of 12 months. from the date of manufacture.

  • Close the bottle tightly after every use.

  • This product is not stable when exposed to freezing temperatures and will not be shipped during such conditions.

Storage & Shipping

  • Is free from any toxic, carcinogenic, mutagenic and reprotoxic chemicals.

  • Does not have a flashpoint and is, therefore, exempt from the Highly Flammable Liquid Regulations.

  • Should be stored away from children.

  • Comprehensive information on the Safety and Handling of Polyzol CTS Plus in Safety Data Sheet

Safety and Handling

CTS229 is made by Kulwong Co., Ltd. with ISO 9001/ISO 14001 Certified by TUV NORD (Thailand) Ltd.

Certified Standards

For further information or other relevant data, please do not hesitate to contact us.
Chaiyaboon Brothers Company (CBC) has a team of well-trained personnel who are ready to give help
and advise regarding product information and application.

Technical Service and Information
